25G SFP28 LWDM LR

RTXM330-892X/893X

RTXM330-89XX LR SFP28 transceiver modules are designed for use in 25 Gigabit Ethernet links on up to 10km of single mode fiber. They are compliant with the SFF-8431, SFP28 MSA, IEEE 802.3cc.The optical transceiver is RoHS compliant.

Inquiry Cart

Contact Us

Key Features

Hot-pluggable SFP28 form factor

Supports 25.78125Gb/s aggregate bit rate

Power dissipation <1.8W

Commercial case temperature range of -40°C to 85°C

Single 3.3V power supply

Maximum link length of 15km on Single Mode Fiber (SMF)

Aligned with IEEE 802.3cc

Cooled DML DFB-based O-band LWDM transmitter

25G NRZ retimed 25GAUI electrical interface

Duplex LC receptacles

I2C management interface

RoHS compliant

Application

Ethernet/CPRI

Specifications

Data Rate

25.78125Gb/s

Distance

10km/15km

Case Temperature

-40~85℃

Voltage Supply

3.3V

Transmitter

Cooled DML O-Band LWDM DFB

Receiver

PIN

Wavelength

O-band 1268.24~1319.42nm

Connector

LC

Power consumption（Max）

1.8W
