100G QSFP28 CWDM4

RTXM420-431

RTXM420-431 100G QSFP28 CWDM4 transceiver modules are designed for use in 100 Gigabit Ethernet links on up to 2km of single mode fiber. They are compliant with the QSFP MSA and CWDM4 MSA.The optical transceiver is RoHS compliant.

Inquiry Cart

Contact Us

Key Features

Hot-pluggable QSFP28 form factor

Supports 103.125Gb/s aggregate bit rate

Power dissipation <3.5W

Commercial case temperature range of 0°C to 70°C

Single 3.3V power supply

Maximum link length of 2km on single Mode Fiber (SMF)

Aligned with 100G CWDM4 MSA

4x25G NRZ DFB-based CWDM transmitter

4x25G NRZ retimed 100GAUI-4 electrical interface

Duplex LC receptacles

I2C management interface

RoHS compliant

Application

DATACOM

Specifications

Data Rate

103.125Gb/s

Distance

2km

Case Temperature

0~70℃

Voltage Supply

3.3V

Transmitter

DFB

Receiver

PIN

Wavelength

CWDM

Connector

Duplex LC

Power consumption（Max）

3.5W
